Genmitsu Milling Bits Database

Stuck In Speed & Feed Rate?

These milling bit data sheets will be used as reference data for end mills for your CNC project, the actual parameters should be adjusted according to your project and material. The bit data file can only be used with the specified Genmitsu item number. Using this file with other brands is dangerous for the operator and the CNC machine.

View Genmitsu CNC Buyer Guide (Click to read)

Milling Bit Tool Files

Fusion 360™ CNC Tool File

Fusion360 has multiple speed and feed options for each toolhead, so the tool database that can be imported into Fusion360 is organized accordingly. It has a common tool database format, which means creating a file for the entire tool database that can be imported.

Carveco® CNC Tool File

There are two tool database files:‘SainSmart Bits (Carveco_Metric).tdb’‘SainSmart Bits (Carveco_Inches).tdb’Apart from the units used for definitions and feed rates these are identical.Import either (or both) into the Carveco Tool database. The bits you have can then be copied, moved… as you see fit to suit your needs and organisation of the tool database.

G-Wizard CNC Tool File

G-Wizard is a speed and feed calculator designed primarily for larger and more expensive CNC routers, but it can also be used for smaller routers. If you use G-Wizard, there is a single file that can be imported into G-Wizard that does not include the speed and feed, because that is what G-Wizard generates and G-Wizard performs the inch conversion internally.

DeskProto CNC Tool File

DeskProto already offered a unique wide range of CAM options in one program:- 3D STL data, 2D vector data and bitmap reliefs- 3-axis, 4-axis and 5-axis- Windows, MacOS and Linux, ...These new extra features make the program even more multifunctional.

Other Software CNC Tool File

To cover any other options two tables are included these contain all the parameters for the bits and speeds and feeds.
